Deye 10 kw trifaze ongrid inverter
Deye 10 kw trifaze ongrid inverter
Normal fiyat
43,320.00TL
Normal fiyat
1,210.00TL
İndirimli fiyat
43,320.00TL
Birim fiyat
/
/
Vergiler dahil.
Teslim alım stok durumu yüklenemedi
Ürün kullanma kılavuzu için : Tıklayınız
| Model | |
|---|---|
| Input Side | SUN-10K-G03 |
| Max. DC Input Power (kW) | 13 |
| Max. DC Input Voltage (V) | 1000 |
| Start-up DC Input Voltage (V) | 200 |
| MPPT Operating Range (V) | 200-800 |
| Max. DC Input Current (A) | 12.5+12.5 |
| Number of MPPT / Strings per MPPT | 2/1 |
| Output Side | |
| Rated Output Power (kW) | 10 |
| Max. Active Power (kW) | 11 |
| Rated AC Grid Voltage (V) | 380 / 400 |
| AC Grid Voltage Range (V) | 277-460 |
| Rated Grid Frequency (Hz) | 50 / 60 (Optional) |
| Operating Phase | Three phase |
| Rated AC Grid Output Current (A) | 14.5 |
| Max. AC Output Current (A) | 16 |
| Output Power Factor | 0.8 leading to 0.8 lagging |
| Grid Current THD | <3% |
| DC Injection Current (mA) | <0.5% |
| Grid Frequency Range | 47-52 or 57-62 (Optional) |
| Efficiency | |
| Max. Efficiency | 98.3% |
| Euro Efficiency | 97.5% |
| MPPT Efficiency | >99% |
| Protection | |
| DC Reverse-Polarity Protection | Yes |
| AC Short Circuit Protection | Yes |
| AC Output Overcurrent Protection | Yes |
| Output Overvoltage Protection | Yes |
| Insulation Resistance Protection | Yes |
| Ground Fault Monitoring | Yes |
| Islanding Protection | Yes |
| Temperature Protection | Yes |
| Integrated DC Switch | Yes |
| Surge protection | DC Type II / AC Type II |
| General Data | |
| Size (mm) | 330W x 430H x 177D |
| Weight (kg) | 15 |
| Topology | Transformerless |
| Internal Consumption | <1W (Night) |
| Running Temperature | -25-60°C |
| Ingress Protection | IP65 |
| Noise Emission (Typical) | <30 dB |
| Cooling Concept | Natural cooling |
| Max. Operating Altitude Without Derating | 2000m |
| Designed Lifetime | >20 years |
| Grid Connection Standard | EN50549, IEC61727 |
| Operating Surroundings Humidity | 0-100% |
| Safety EMC / Standard | IEC62109-1/-2, EN61000-6-1, EN61000-6-3 |
| Features | |
| DC Connection | MC-4 mateable |
| AC Connection | IP65 rated plug |
| Display | LCD1602 |
| Interface | RS485 / RS232 |
